Technical parameters:

Voltage: 12V

Nominal airflow: 700 m3/h

This heat exchanger has a 3-speed fan

Heating capacity, Ethylene glycol: 11.9 kW

4 x ø60 mm air sleeves for even hot air distribution

Inlet & outlet for ethylene glycol: ø16 mm

Maximum allowable inner temperature °C: 100

Maximum reachable inner temperature with AUTOTERM Flow series heater °C: 88

For fan speed control optional 4-position rotary switch FR018 is required.

* 4-pin connector kit FR051 is available separately - not included in the kit.

This liquid heat exchanger with a fan is suitable for all the following liquid heaters:

• AUTOTERM Flow 5 D / B
• AUTOTERM Flow 14D

Manufacturer: SIROCO
