Technical parameters:

Voltage: 24V

Nominal airflow: 347 m3/h

This heat exchanger has a 3-speed fan

Heating capacity, Ethylene glycol: 5.9 kW

Inlet & outlet for ethylene glycol: ø16 mm

The front panel of the liquid heat exchanger is heat-resistant & removable

Maximum allowable inner temperature °C: 100

Maximum reachable inner temperature with AUTOTERM Flow series heater °C: 88

* 2-pin connector kit FR052 is available separately - not included in the kit.

Liquid heat exchanger with the fan is suitable for all the following liquid heaters:

• AUTOTERM Flow 5 D / B
• AUTOTERM Flow 14D
